ZX130-7

The ZX130-7 medium excavator enables you to increase your profits and reduce running costs due to its exceptional reliability, efficiency and productivity. The Stage-V compliant model has a state-of-the-art cab with first-class comfort and safety features.



Engine Rated Power (kW): 74 kW (ISO14396)
Operating weight (kg): 13 600 - 15 800 kg
Backhoe Bucket ISO Heaped: 0.19 - 0.66 m3
Available in: Europe

The ZX130-7 medium excavator enables you to increase your profits and reduce running costs due to its exceptional reliability, efficiency and productivity. The Stage-V compliant model has a state-of-the-art cab with first-class comfort and safety features.



Quotation Request
Find A Dealer
Compare Model
Overview
About the ZX130-7

You can expect the highest quality, outstanding versatility and guaranteed maximum uptime with the new Hitachi ZX130-7 medium excavator. Its Stage V-compliant engine does not require an SCR system, which results in reduced life-cycle costs.

Benefits
Discover the benefits
  • Up to 9% reduced fuel consumption compared to previous models.
  • Enhanced efficiency due to Hitachi’s industry-leading hydraulic system, HIOS V.
  • The Stage V-compliant engine does not require an SCR system, eliminating the need for urea, filter replacements and associated maintenance.
  • Improved comfort in the cab with integrated console and seat suspension, reduced noise and low vibration levels.
Download Brochure
Specifications

Specifications for the ZX130-7 Excavator

Expand all Collapse all
  • Engine & hydraulic system
Engine Model TOYOTA INDUSTRIES CORPORATION 1KDE
Engine Type 4-cycle water-cooled, common rail direct injection
Aspiration Turbocharged, intercooled, cooled EGR
Aftertreatment DOC und DPF
No. of cylinders 4
Piston displacement 15.681 L
Rated power ISO 14396 74 kW at 2 000 min-1
Maximum torque 390 Nm at 1 700 min-1
Main pumps 2 variable displacement axial piston pumps
Maximum oil flow 2 x 117 L/min
Pilot pump 1 gear pump
Maximum oil flow pilot pump 33.6 L/min.
  • Bucket and arm digging force
Bucket digging force ISO 104kN
Arm crowd force ISO 77kN
  • Operating weight and ground pressure
Shoe type Triple grouser
Shoe width 500 - 700 mm
Arm length 2.10m
Monoblock weight 13,600 – 15,300 kg
Monoblock pressure 31 – 47 kPa
2-Piece weight 14,200 – 15,800 kg
2-Piece pressure 32 – 48 kPA
  • Working ranges
Arm length 2.10 - 3.01 m
Max. digging reach 7 940 - 8 770 mm
Max. digging depth 5 120 - 6 030 mm
Max. dumping height 5 990 - 6 520 mm
  • Dimensions
Undercarriage length 3.580 mm
Undercarriage width 2.490 mm
Overall width of upper structure 2.460 mm
Overall height of cab 2.790 mm
  • Specifications
Engine Rated Power (kW) 74 kW (ISO14396)
Operating weight (kg) 13 600 - 15 800 kg
Backhoe Bucket ISO Heaped 0.19 - 0.66 m3
Max. digging depth (mm) 5 120 - 6 030 mm
Bucket digging force (kN) ISO 104kN
Download Brochure
Attachments
Attachments enhance the performance of your ZX130-7
  • Durable hydraulic breakers, buckets and ground engaging tools will increase your profit by maximising productivity and uptime.
  • Choose from a wide range of Hitachi buckets to suit the application. Quick coupler connections are also available.
  • Hitachi-approved breakers are easy to maintain, user-friendly, and high-quality materials ensure a long lifetime.
  • Hitachi ground engaging tools (GET) fit precisely to your attachments, and are quick and safe to install and replace.
Download Brochure

Try before you buy with Hitachi Premium Rental

You can rent a wide range of Hitachi excavators and wheel loaders direct from Hitachi via our dealer network. Hitachi Premium Rental machines can be hired by the month and for periods up to one year. This gives you the high levels of reliability, quality and service you would expect from Hitachi, and greater flexibility to meet the varying demands of your business.

Find out more about Hitachi Premium Rental

Want to find out more?

For more information on the new Hitachi machinery, the Hitachi Premium Rental programme, or to discuss your needs in more detail, please fill out the form.



One of our specialists will contact you within a couple of days of your enquiry.
