Overview
About the ZX220W-7

You can work on a wide range of projects with the versatile Hitachi ZX220W-7 wheeled excavator. Attachments are easily changed using the enhanced attachment support system and can be conveniently transported using the optional trailer support package.

Benefits
Discover the benefits
  • HIOS III hydraulic system enhances productivity with reduced fuel consumption.
  • All-new ECO gauge allows operators to control fuel efficiency and reduce costs.
  • Excellent visibility due to the Aerial Angle camera system and new LCD monitor.
  • Industry-leading comfort in the expanded cab with low noise and vibration levels.
Specifications

Specifications for the ZX220W-7 Wheeled Excavator

Expand all Collapse all
  • Engine & hydraulic system
Engine Model Isuzu 4HK1X
Engine Type 4-cycle water-cooled, common rail direct injection
Aspiration Variable geometry turbocharged, intercooled, cooled EGR
After-treatment DOC+CSF+SCR system
No. of cylinders 4
Rated power ISO 14396 128.4 kW at 2 000 min-1
Maximum torque 670 Nm at 1 600 min-1
Main pumps 2 variable displacement axial piston pumps
Piston displacement 5.193 L
Bore and stroke 115 mm x 125 mm
Batteries 2 x 12 V / 126 Ah
  • Bucket and arm digging force
Bucket digging force ISO 158kn
Arm crowd force ISO 140kn
  • Working ranges
Max. digging reach 9 790 - 10 280 mm
Max. digging depth 5 810 - 6 300 mm
Max. dumping height 7 040 - 7 390 mm
  • Dimensions
Overall width of upperstructure 2 480mm
Overall height of cab 3 215mm
Overall width of tires 2 540mm
Overall width 2 470 - 3 910 mm
  • Specifications
Engine Rated Power (kW) 128 kW
Operating weight (kg) 20 100 - 24 900 kg
Backhoe Bucket ISO Heaped 0.51 - 1.20 m3
Max. digging depth (mm) 5 810 - 6 300 mm
Bucket digging force (kN) ISO 158kn

Try before you buy with Hitachi Premium Rental

You can rent a wide range of Hitachi excavators and wheel loaders direct from Hitachi via our dealer network. Hitachi Premium Rental machines can be hired by the month and for periods up to one year. This gives you the high levels of reliability, quality and service you would expect from Hitachi, and greater flexibility to meet the varying demands of your business.
