Overview
High levels of safety

Safety levels are high on the EH4000AC-3 thanks to its Aerial Angle feature. A camera monitor is positioned on the left-front pillar of the cab, which significantly enhances visibility. The monitor displays the view from four cameras located around the truck, allowing the operator to see ground-level obstacles.



A variety of features have been added for safe and easy maintenance. Its four air filters are easily accessible and fitted with evacuator valves, while the battery and relay boxes are located at ground level. The collapsible step and flat service stage inside the rear axle is also convenient for quick servicing.

Specifications

Specifications for the EH4000AC-3

Expand all Collapse all
  • Engine
Engine Model Cummins QSKTA60-CE (T2)
Engine Model MTU 12V4000 C21 (Not Certified)
  • Tires
Tire size Rim Width : 46/90R57 (standard) 736.6 mm (29 in.)
: 40.00R57 (optional) 736.6 mm (29 in.)
: 50/80R57 (PLUS specs.) 736.6 mm (29 in.)
  • Dimensions
Overall length 14 390 mm (47 ft. 3 in.)
Overall width 9 330 mm (30 ft. 7 in.)
  • Specifications
Nominal payload (kg) with Standard Equipment : 221 tonnes (243.6 tons)
Gross machine operating weight (kg) 384 000 kg (846,575 lb.)
Engine Rated Power (kW) Standard : Cummins QSKTA60-CE : 1 864 kW (2 534 PS, 2 500 HP) / Optional : MTU 16V4000 C21 : 1 864 kW (2 534 PS, 2 500 HP)
Max. travel speed (km h) 56 km/h (35 mph)
